Motherboard Gigabyte B450m Aorus Elite Am4

Descripción:

PREPÁRESE PARA LA SERIE AMD RYZEN ™ 3000
Las motherboard GIGABYTE AM4 están listas para admitir los últimos procesadores AMD Ryzen ™ 3000 y son compatibles con los procesadores AMD Ryzen ™ 2000 y 1000. Con una rica lista de características en las placas base GIGABYTE AM4, como Ultra Durable ™ Armor para ranuras PCIe / memoria, interfaces USB Type-C ™ en placas seleccionadas, calidad de audio refinada, Ethernet de alta velocidad y el último diseño WIFI estándar, motherboard GIGABYTE AM4 son perfectos para usuarios que buscan construir los mejores sistemas de plataforma AMD.
Motherboard AMD B450 AORUS con PWM digital híbrido, M.2 dual con una protección térmica, RGB FUSION 2.0, LAN de juegos GIGABYTE con gestión de ancho de banda, preparado para CEC 2019

S Admite AMD 3rd Gen Ryzen ™ / 2nd Gen Ryzen ™ / 1st Gen Ryzen ™ / 2nd Gen Ryzen ™ con Radeon ™ Vega Graphics / 1st Gen Ryzen ™ con Radeon ™ Vega Graphics / Athlon ™ con Radeon ™ Vega Graphics Processors
DDR4 sin búfer sin ECC de doble canal, 4 DIMM
HDMI, puertos DVI-D para pantallas múltiples
Escudo de I / O integrado de diseño Ultra Durable ™
Doble NVMe PCIe Gen3 M.2 ultrarrápido (x4, x2) con un protector térmico
Condensadores de audio de alta calidad y protección contra ruido de audio con iluminación de trayectoria de seguimiento LED
RGB FUSION 2.0 con diseño de espectáculo de luces LED multizona, compatible con tiras de LED digital y RGB LED
LAN exclusiva para juegos 8118 de GIGABYTE con gestión de ancho de banda
Smart Fan 5 cuenta con 6 sensores de temperatura y 4 cabezales de ventilador híbridos con FAN STOP
Centro de aplicaciones que incluye las utilidades EasyTune ™ y Cloud Station ™
Listo para CEC 2019, ahorre energía con un simple clic

Especificaciones:

• Marca: Gigabyte
• Modelo: B450 AORUS
• Codigo del fabricante: B450 AORUS ELITE (rev. 1.x)
• Codigo del producto: 889523020548
• CPU: AM4 Socket: Supports AMD Ryzen™ 5000 series/ 3rd Gen Ryzen™/ 2nd Gen Ryzen™/ 1st Gen Ryzen™/ 2nd Gen Ryzen™ with Radeon™ Vega Graphics/ 1st Gen Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors
• CHIPSET: AMD B450
• MEMORIA: -4 x DDR4 DIMM sockets supporting up to 128 GB of system memory. -Dual channel memory architecture. -Support for DDR4 3600(O.C.)/3466(O.C.)/3200(O.C.)/2933/2667/2400/2133 MHz memory modules. -Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode). -Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules. -Support for Extreme Memory Profile (XMP) memory modules.
• GRAFICOS: Integrated Graphics Processor: -1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz. * The DVI-D port does not support D-Sub connection by adapter. -1 x HDMI port, supporting a maximum resolution of 4096x2160@60(Note) Hz. * Support for HDMI 2.0 version and HDCP 2.2.(Note). Maximum shared memory of 16 GB
• RANURAS DE EXPANCION: 1 x PCI Express x16 slot, running at x16 (PCIEX16)(Note). * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. (The PCIEX16 slot conforms to PCI Express 3.0 standard.). -1 x PCI Express x16 slot, running at x4 (PCIEX4)* The PCIEX4 slot shares bandwidth with the PCIEX1_2 slot. The PCIEX4 slot operates at up to x2 mode when the PCIEX1_2 slot is populated. The PCIEX4 slot operates at up to x4 mode when the PCIEX1_2 is empty. -2 x PCI Express x1 slots (The PCIEX4 and PCIEX1 slots conform to PCI Express 2.0 standard.). Tecnología Multi-Gráficos: Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies
• ALMACENAMIENTO: -1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support) (M2A_SOCKET). -1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 PCIe 3.0 x2 SSD support)(M2B_SOCKET). -6 x SATA 6Gb/s connectors. Support for RAID 0, RAID 1, and RAID 10* Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors.
• RED DE DATOS INALAMBRICA: No aplica
• BLUETOOTH: No aplica
• AUDIO: -Realtek® Audio CODEC. -High Definition Audio. -2/4/5.1/7.1-channel. -Support for S/PDIF Out
• LAN: Realtek® GbE LAN chip (10/100/1000 Mbit)
• PUERTOS USB: -Chipset: -2 x USB 3.1 Gen 1 ports available through the internal USB header. -8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers). Integrated in the APU: -4 x USB 3.1 Gen 1 ports on the back panel.
• INTERNAL I/O: -1 x 24-pin ATX main power connector. -1 x 8-pin ATX 12V power connector. -2 x M.2 Socket 3 connectors. -6 x SATA 6Gb/s connectors. -1 x CPU fan header. -3 x system fan headers. -1 x CPU cooler LED strip/RGB LED strip extension cable header. -1 x RGB (RGBW) LED strip header. -2 x digital LED strip headers. -2 x digital LED strip power select jumpers. -1 x front panel header. -1 x front panel audio header. -1 x S/PDIF Out header. -1 x USB 3.1 Gen 1 header. -2 x USB 2.0/1.1 headers. -1 x Trusted Platform Module (TPM) header (2x10 pin, for the GC-TPM2.0 module only). -1 x serial port header. -1 x Clear CMOS jumper
• BIOS: 1 flash de 128 Mbits. Uso de BIOS AMI UEFI con licencia. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
• FACTOR DE FORMA: factor de forma ATX; 30,5 cm x 23,5 cm
